Coating Line Cooling Tunnel
SELMI TUNNEL 300/400
Designed for coating and cooling coated and moulded products by using a special air diffuser placed along the entire length of the cooling chamber. Production speed ranges from 30 to 200 cm/min.
Tunnel 300/400 features a fully integrated coating section that can be easily removed and washed. The machine is designed to allow conversion after changing the coating, so it can work with multiple tempering machines.
Key Features
- •For large workshops and small/medium-sized industry
- •Can be used simultaneously for coatings and moulds
- •Can be connected to a separator
- •Three-phase, 220 V – 50/60 Hz change option
Technical Specifications
- Electrical: 400 V three-phase 50 Hz
- Power: 4 kW – 16 A – 5-pole
- Optimal temperature: 20/25°C, max. 32°C
- Cooling: 3800/4000 frigories/hour
- Dimensions: l. 6/8/12 mt, d. 850 mm
- Working width: 300/400 mm
